OG308

Ultra-slim Commercial DMR Radio

Lightweight AI Bluetooth OEM/ODM
OG308 adopts a lightweight and modern design, bringing new possibilities and trends in the commercial radio field. Apart from the fashionable and simple appearance with a sense of technology, it also has excellent communication performance such as AI noise reduction, data encryption, and channel copy, etc. as well as special features such as APP programming, Bluetooth application, voice broadcast, etc. OG308 is equipped with 2200mAh battery, which can be used continuously for 16 hours, bringing the ultimate communication experience for commercial users.
Inquiry
Inquiry
OG308
Ultra-slim Commercial DMR Radio
Inquiry

Highlights

Ultra-Slim Design

OG308 adopts a lightweight design with only 15mm and 140g. The overall appearance of fashionable simplicity and sleek lines effectively reduces the radio’s heavy feeling and enhances its portability, even if a child can easily operate it.

Hidden Display

OG308 adopts the integrated design of the rest screen, equipped with an LED matrix display to balance the aesthetic. Meanwhile, it can more intuitively show the terminal status, even if the outdoor activities or messy light scenarios can still easily recognize the working status.

AI Noise Reduction

OG308 uses the AI algorithm to recognize and separate the human voice and noise, processing audio signals in real-time and filtering the environment’s noise effectively, to guarantee crystal clear communication in various complicated scenes.

Wide Coverage

OG308 is equipped with high-power RF, which can not only realize the urban calls but also ensure the clear and stable communication effects in various complex environments. No matter in outdoor adventure, construction site operation, or shopping mall dispatching, OG308 always can meet the user’s needs for communication distance and clarity to achieve barrier-free communication.

Channel Copy

Having a farewell with the complicated frequency matching via computer, OG308 can copy another frequency channel within seconds with the channel copy function, which can rapidly organize multi-user communication at the same time under the same frequency.

Emergency Alarm

During emergencies, the emergency alarm of OG308 will send the alerting signal and the locations in time to guarantee personnel safety and make a rapid and coordinated response in critical situations.

Bluetooth Connection

OG308 supports Bluetooth 5.0, which allows you to connect mobile phone APP for frequency adjustments and terminal settings. Bluetooth wireless earphones, headsets, and other peripherals are also used for audio transmission and real-time calls.

VOX

OG308 is designed for situations like driving vehicles, outdoor activities, or hands needed to operate other devices. After turning on VOX, users can still talk with no need to press the PTT button, so users can free their hands and communicate more freely.

Specifications

General
Frequency Range UHF:400-480 MHz
Channel Capacity ≤ 125
Zone 1
Channel Spacing 12.5KHz/25KHz
Working Voltage DC 3.8V
Battery Capacity 2200mAh
Average Battery Life(5/5/90) Digital 15 hours Analog 10 hours
Frequency Stability ±0.5ppm
Antenna Impedance 50Ω
Working Current Receiving: 400mA Transmitting: 2500mA
Dimension 52.7 (L) *16.6 (W) *115 (H)mm
Weight 135.6g (including battery)
Bluetooth BT5.0
Transmitter
Power Output ≤ 4W
4FSK Modulation 12.5kHz data only: 7K60FXD; 12.5kHz data and voice: 7K60FXE
FM Modulation 12.5 kHz: 8K50F3E; 25 kHz: 16KΦF3E
Modulation Limitation +/- 2.5kHz @ 12.5kHz; +/- 5kHz @ 25kHz
FM Noise -40dB
Spurious Emission -36 dBm≤1GHz/-30 dBm≥1GHz
Adjacent Channel Power ≤-60dB
Frequency Response +1/-3 dB
Digital protocol DMR
Free time slot power ≤-57dBm
Digital Vocoder AMBE3000
Receiver
Digital Sensitivity 5% BER:0.25 uV
Analog Sensitive 0.25 uV (12 dB SINAD)
Intermodulation 65dB
Adjacent Channel Selection 60 dB
Spurious Suppression 70 dB
FM Noise -40dB
Frequency Response +1/-3 dB
Rated Audio Distortion 0.5W
Maximum Audio Power 1W
Rated Audio Distortion 0.03
Harmonic suppression ≤-70dBm
If Rejection ≤-70dBm
Co-channel suppression ≤-70dBm
Image Rejection ≤-70dBm
Conduction Radiation ≤-57dBm
Spurious radiation ≤-57dBm
Block >84dBm
Environmental Specifications
Operational Temperature -20℃—+60℃
Storage Temperature -30℃—+85℃
Dust & Water Proof IP54
